AELAB UV VIS Spectrophotometer Single Beam AE-S60-2U AE-S60-4U
AE-S60 SeriesCan display wavelength, absorption and transmittance with 5 results per screen. It also has a memory store of up to 200 results.
* It can set up various standard curves according to customer/s solutions and find the concentration of unknown solutions.
* Equipped with imported deuterium lamp which ensures low stray light, photometric accuracy and is easy to be replaced.
Features:
+ Single beam spectrophotometer with highly stable optics.
+ 6 inches & compact LCD display. Integrated user interface.
+ Extremely versatile with full functionality
+ UV range: 190 to 1100nm, VIS range:320-1100nm.
+ Spectral bandwidth 1.8 & 2nm.
+ USB port for data storage.
+ ISO/CE Certificate passed.
+ A & E Lab PC software available.
+Extensive range of accessories available.
Functions:
T Mode: Continuously measure the Transmittance of samples
A Mode: Continuously measure the Absorbance of samples
C Mode: Standard Curve method, can use at most 9 standard samples to create a new standard curve, and to measure the unknown samples by the new one.
F Mode: Coefficient Method, Input the known K and C to measure the unknown concentration samples.
Ordering Models:
Order Code | Description |
AE-S60-2U | Single beam,UV-VIS Spectrophotometer,LCD display | Wavelength range 190-1000nm, Bandwith: 2nm |
AE-S60-4U | Wavelength range 200-1000nm, Bandwith: 4nm. |
AE-S60-4V | Single beam,Visible Spectrophotometer,LCD display | Single Beam,325-1000nm, Bandwith: 4nm. |
Technical Specifications:Wavelength |
Wavelength Range | UV range: 190-1000nm Visible Range: 325-1000nm |
Wavelength Accuracy | ±1nm |
Wavelength Repeatability | 0.5nm |
Band Width | 2nm/4nm |
Wavelength Setting | Auto |
Photometric |
Photometric Accuracy | ±0.5%T |
Photometric Repeatability | 0.3%T |
Photometric Display Range | 0-200%T, -0.3-3.0A, 0-9999C |
Stability | 0.002A/h @ 500nm |
Noise | ±0.001A |
Stray Light | ≤0.3%T @220nm, 360nm |
Others |
Data Output Port | USB |
Printer Port | Parallel Port |
Optical System | Single Beam (1200 lines/mm grating) |
Display | AE-S60: 128x64 Dots LCD |
Lamps | Deuterium & Tungsten Halogen Lamp |
Detector | Silicon Photodiode |
Software | UV or VIS software |
Power Supply | AC 220V/50Hz, 110V/60Hz. |
Packing Size & Gross Weight | 57x45x31cm & 13kg |
Spectrophotometer Optional Accessories
Spectrophotometer Optional Accessories
