Model NO.
AE-RE2
+ Large LCD digital display indicates rotation speed, heating temperature and time.
+ User friendly operation with automatic motor lift.
+ Automatically lift the evaporation flask out of the bath in case of accidental power failure.
+ 5L flask capacity heating bath with stainless steel interior, compatible with both water and oil bath.Water/oil heating mode can be changed only through a switch.
+ Safety circuits prevent overheating at 220°C and these can be used for high temperature evaporation.
+ Chemically resistant PTFE sealing ring designed to be vacuum tight.
+ USB interface for data documentation and control through PC.
+ Vertical condenser with large surface area of 1700 cm2 provides excellent cooling effect.
+ Wide variety of glassware suitable for various applications.
Quantity:
AELAB Rotary Vacuum Evaporator Vertical AE-RE2

Features:


+ Large LCD digital display indicates rotation speed, heating temperature and time.
+ User friendly operation with automatic motor lift.
+ Automatically lift the evaporation flask out of the bath in case of accidental power failure.
+ 5L flask capacity heating bath with stainless steel interior, compatible with both water and oil bath.Water/oil heating mode can be changed only through a switch.
+ Safety circuits prevent overheating at 220°C and these can be used for high temperature evaporation.
+ Chemically resistant PTFE sealing ring designed to be vacuum tight.
+ USB interface for data documentation and control through PC.
+ Vertical condenser with large surface area of 1700 cm2 provides excellent cooling effect.
+ Wide variety of glassware suitable for various applications.


Technical Specifications:

 SpecificationsAE-RE2AE-RE2-H
TypeVerticalHorizontal
Motor TypeBrushless DC motor
Speed Range20-280rpm
DisplayLCD (speed,temperature,time)
Clockwise and Anti-clockwiseYes
Heating Temperature RangeRoom temp. to 180℃
Control Accuracywater: ±1℃,oil: ±3℃
Heating Power1300W
Stroke Displacementautomatic 150mm
TimerYes
Time Setting Range1-999min
Dimension[D×W×H]465×457×583mm

Weight15kg
Permissible Ambient Temperature5-40℃
Permissible Relative Humidity80%RH
Protection ClassIP20
USB InterfaceYes
Voltage/Frequency100-120/200-240V 50/60Hz
Power1400W
