AELAB Nucleic Acid Purification System Auto-Pure48
AELAB Nucleic Acid Purification System Auto-Pure48

AELAB Nucleic Acid Purification System Auto-Pure48

Model NO.
Auto-Pure48
+ Operational advantages
+ Simple and intelligentized operation
+ High throughput, fast extraction and modular design can meet variety of needs by one unit.
Quantity:
AELAB Nucleic Acid Purification System Auto-Pure48

Features:
*High throughput, fast extraction and modular design can meet variety of needs by one unit.
*Operational advantages
1. High-throughput:
Auto-Pure 48 can process 48x3ml samples simultaneously
2. Open and multiple functions design can be provided more methods for reagent optimization, and also a reliable choice
3. Touchscreen interface and easy operation, parameters can be tuned based on experimental requirements
4. Accurate temperature control system ensures stability of purification performance
5. Patent structure design with center rotary table which makes it occupies smaller area
6. Patent design for automatic loading and unloading structure of magnetic rod tip comb, which guaranteed stability and liability (Success rate >99.99%)
*Antipollution measures
1. Avoid reagent splashing through drip shield plate and beads dried way controlled by software
2. Disposable consumables which can avoid cross contamination
*Simple and intelligentized operation
1. Front door can be opened, you can stop it at any moment which is very convenient for reagent optimization and experimental status viewing
2. Start with self-check, equipped with power-off protection
3. 8-plate identification design guaranteed their target position, even though external forces exist
4. Automatic detection in case kit missing.

Technical Specifications:
TypeAuto-Pure 48
Throughput1~48
Process volume200~3000μl
Collection efficiency>95%
Magnetic rod number48
Purification accuracy100 copy sample positive rate>95%
StabilityCV<5%
Plate types48x5ml plate
Healting for lysis tubeAmbient temperature~120°C
Heating for elution tubeAmbient temperature~120°C
Operation7 inch color touch screen
Extraction stepsLysis, binding, washing and elution
Storage capacitymore than 100 programs
Protocol managementCreate, edit, delete, protocol mode
Pollution controlUV light
LightingYes
Extension interface4 standard USB port, built-in SD card
ExhaustFan
Power supply450W
Dimension560×620×500mm
Weight54kg
