AELAB Jupiter Series High Throughput Closed Microwave Digestion/Extraction Workstation
AELAB Jupiter Series High Throughput Closed Microwave Digestion/Extraction Workstation

AELAB Jupiter Series High Throughput Closed Microwave Digestion/Extraction Workstation

Model NO.
Jupiter Series
+ Satisfy the requirements of different samples' digestion / extraction processing;
+ Up to 12 vessels high-throughput processing capacity;
+ Exclusive patented multifunctional safety bolt design, instead of explosion-proof membrane and other consumables
+ Aerospace composite fiber outer vessel-the highest level of security measures;
+ Large-screen color software interface, clear and direct-viewing in operation, bright in appearance and smart in performance.
+Connected to and controlled by computer, achieving secure remote operation, and unlimited program storage database;
+ Small volume VS big chamber, which is advance in industrial design and provides perfect experience;
+ Free lifetime warranty to the core components - magnetron of the microwave Digestion System;
+ 20 years of industry experience with no life injury;
+ Won China’stop award-BCEIA GOLD four times and leads in the number of users nationally;
Quantity:
AELAB Jupiter Series High Throughput Closed Microwave Digestion/Extraction Workstation
Feature:
+ Satisfy the requirements of different samples' digestion / extraction processing;
+ Up to 12 vessels high-throughput processing capacity;
+ Exclusive patented multifunctional safety bolt design, instead of explosion-proof membrane and other consumables
+ Aerospace composite fiber outer vessel-the highest level of security measures;
+ Large-screen color software interface, clear and direct-viewing in operation, bright in appearance and smart in performance.
+Connected to and controlled by computer, achieving secure remote operation, and unlimited program storage database;
+ Small volume VS big chamber, which is advance in industrial design and provides perfect experience;
+ Free lifetime warranty to the core components - magnetron of the microwave Digestion System;
+ 20 years of industry experience with no life injury;
+ Won China’stop award-BCEIA GOLD four times and leads in the number of users nationally;

Main Technical Parameters of JUPITER
Power220-240 VAC 50/60Hz  8A
Microwave frequency2450MHz
Installed power1800W
Maximum output power1300Wnon-pulse continuous automatic variable frequency control
Turntable designLoad 12 JP-100 closed digestion vessels at same time
(standard configuration is 10 vessels)
Pressure measurement and control systemPiezoelectric crystal pressure sensor, pressure control range :0-10MPa (1500 psi), accuracy ± 0.01MPa
Temperature measurement and control systemHigh-precision platinum resistor temperature sensor, temperature range :0-300°C, accuracy ±1
Outer vessel materialExplosion-proof outer vessel made of aerospace composite fiber
Inner vessel materialModified TFM material
SoftwareJUPITER-A apply JSs software. 5 inch color screen display, USB connection, can save unlimited amount of digestion solution.Simplified JUPITER-B apply JSb software.5 inch screen display and up to 50 methods can be stored.
Chamber exhaust systemHigh-power anticorrosion axial fan, exhaust speed: 3.1 m3/min
Operating ambient temperature0-40 °C
Working environment humidity15-80%RH
Whole physical size450*600*620mm (Width x Depth x Height)
Net weight:42 KG
